CM-HT12/CU-T Solar Power Heliport Perimeter Lights (Elevated)
Solar Power Heliport perimeter lights are vertical installation lamp. An omnidirectional green light signal can be emitted during the night or during low visibility to facilitate indicating the safe landing area to the pilot. The switch is controlled by the heliport light control cabinet.
Production Description
Compliance
| - ICAO Annex 14, Volume I, Eighth Edition, dated July 2018 |
● The lampshade is made of UV (ultraviolet)-resistant PC (polycarbonate) material with a transparency of more than 95%. It has flame retardant, non-toxic, excellent electrical insulation, dimensional stability, corrosion resistance, high temperature resistance and cold resistance.
● The lamp base is made of precision die-cast aluminum and the outer surface is sprayed with outdoor protective powder, which has the characteristics of high strength, corrosion resistance and anti-aging.
● The reflector designed based on the reflection principle has a light utilization rate of more than 95%. At the same time, it can make the light angle more precise and the viewing distance longer, completely eliminating light pollution.
● The light source adopts LED cold light source with high efficiency, low power consumption, long life and high brightness.
● The power supply is designed to synchronize the signal level with the mains voltage and is integrated into the power cable, eliminating damage caused by incorrect installation.
● Lightning protection: Built-in anti-surge device makes the circuit work more reliable.
● The entire lighting device adopts a fully encapsulated process, which is resistant to impact, vibration and corrosion, and can be used for a long time in harsh environments. The structure is light and strong, and the installation is simple.
| Product Name | Elevated Perimeter Lights |
| Overall Size | Φ173mm×220mm |
| Light Souce | LED |
| Emitting Color | Yellow /Green/White/Blue |
| Flash Frequency | Steady-on |
| Lighting direction | Horizontal omnidirectional 360° |
| Light Intensity | ≥30cd |
| Power Consumption | ≤3W |
| Light lifespan | ≥100000 hours |
| Ingress Protection | IP65 |
| Voltage | DC3.2V |
| Solar Power Panel | 9W |
| Net Weight | 1kg |
| Installation dimensions | Φ90～Φ130-4*M10 |
| Environment Humidity | 0％～95％ |
| Ambient Temperature | -40℃┉+55℃ |
| Salt Spray | Salt spray in the air |
| Wind Load | 240km/h |
The installation of lamps and battery boxes is as shown in the figure below. Before installation, anchor bolts should be made (no need to embed them if expansion bolts are used).
Place the lamp horizontally, and the anchor bolts or expansion bolts should ensure firmness and verticality.
Open the battery box and insert the battery plug into the control board.
battery plug
Battery plug pairing point on the control board
Insert the lamp butt connector into the battery box and tighten the connector.
Lamp to plug
